50L Automatic Vacuum Emulsifying Mixer For Chemical Production Line

50L Automatic Vacuum Emulsifying Mixer for Chemical Production Line

Product Introduction

Our vacuum emulsifying mixers deliver critical advantages in industries demanding exact emulsion quality—particularly cosmetics, pharmaceuticals, and food processing. By operating under vacuum, these systems significantly enhance product stability, prevent aeration defects, and extend shelf life through superior homogenization essential for premium end-products.

Features

The tank cover features manual or automated lifting capability, enabling direct vacuum transfer of materials from water/oil vessels to the emulsification chamber via dedicated pipelines. Precise thermal control is achieved through jacketed heating - where heat transfer media within the interlayer elevate material temperatures to user-defined setpoints with automated regulation. Rapid cooling is facilitated by circulating coolant through the same interlayer, with thermal insulation externally applied for efficiency.

Equipment Operation Guidelines

1. PROHIBITED ACTIONS
⚠️ (1) NEVER allow the homogenizer to idle for extended periods
⚠️ (2) NEVER operate the dispersion blade without materials
⚠️ (3) NEVER lean over vacuum tank openings while mixers are running
⚠️ (4) NEVER introduce hard objects (iron, stones, etc.) into vacuum/dispersion tanks

2. REQUIRED OPERATIONS
✅ (1) Ensure manhole valves are fully sealed BEFORE activating vacuum pump
✅ (2) Clean tank interiors ONLY AFTER stopping dispersion blades
✅ (3) Open manholes AFTER confirming ALL stirring and homogenizing functions have ceased
